General description
| Article number | 100-8064 |
| Warranty | 2 year |
| Article status | Active |
| Shock operating | IEC 60068-2-27 (15G) |
| Vibration resistence | Sine vibration (based on IEC 60068-2-6), 5 ~ 25Hz: ±1.6mm, 25 ~ 300Hz: 4G, Sweep rate: 1 octave/min., 20 cycles, Random vibration (based on IEC 60068-2-64), 10 ~ 40Hz: 0.0125g²/Hz, 40 ~ 100Hz: 0.0125 → 0.002g²/Hz, 100 ~ 500Hz: 0.002 g²/Hz, 500 ~ 2000Hz: 0.002 → 1.3 x 10-4g²/Hz, Test time: 1hrs for each test |
| Industrial emissions | EN 61000-6-4/A11: 2011 |
| Industrial immunity | EN 61000-6-2:2005 |
| Installation position | Horisontal, Vertical |
| Product certifications | CE, UL, FCC, RoHS, China RoHS, Reach |
| Power dissipation | Max. 50mA @ 5VDC |
| Isolation | I/O to Logic: Photocoupler isolation, I/O to Field Power: Non-Isolation |
| Field power | Nominal supply voltage: 24VDC, Voltage range: 60℃: 18~32VDC, 70℃: 18~26.4VDC |
| Weight | 65g |
| Module size | 12x109x70mm |
Environmental
| Mounting | 35mm DIN rail |
| Operating temperature | -40 ~ 70℃, Degraded performance > 60℃ |
| Storage temperature | -40 ~ 85℃ |
| UL temperature | -20 ~ 60℃ |
| Relative humidity | 5 ~ 90% non-condensing |
