| Wire type and power | AC 2-wire type 100-240VAC~ |
|---|---|
| Sensing side diameter | M30 |
| Sensing distance | 15mm |
| Standard sensing target | 50×50×1mm(iron) |
| Response frequency | 20Hz |
| Current specification | Leakage current: Max. 2.2mA |
| Control output | Normally Closed |
| Material | Brass(nickel plated) |
| Protection structure | IP65 |
| Environment_Ambient temperature | -25 to 70℃, storage: -30 to 80? |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Hysteresis(distance) | Max. 20% of sensing distance |
| Weight | Approx. 237g(approx. 200g) |
