| Mechanical size |
409 x 270 x 43 mm
Panel Mount
|
||||
| Cut-out size | 393 x 254 mm | ||||
| Housing material | Plastic (PC+ABS), Gray | ||||
| Input voltage | 18-32 VDC | ||||
| CPU | ARM Cortex A8 1000MHz | ||||
| RAM | 512 MB | ||||
| FLASH | 2 GB | ||||
Size diagonal |
15.6" diagonal | ||||
| Resolution | 1366x768 pixels | ||||
| Number of serial ports | 1port9pinDsub, 1port3pinScrew | ||||
| Serial port 1 | RS 232 (RTS/CTS) | ||||
| Serial port 2 | RS422/485 | ||||
| Serial port 3 | RS 232 | ||||
| Serial port 4 | RS 485 | ||||
| Number of Ethernet ports | 2 | ||||
| Ethernet port 1 |
1x10/100 Base-T
(shielded RJ45)
|
||||
| Ethernet port 2 |
1x10/100 Base-
T (shielded RJ45)
|
||||
| Operating temperature | -10°C to +50°C | ||||
| Sealing front | IP65 | ||||
