| Mechanical size | 204 x 143 x 50 mm Panel Mount | ||||
| Cut-out size | 189 x 128 mm | ||||
| Housing material | Powder-coated aluminum, Black | ||||
| Input voltage | 18-32 VDC | ||||
| CPU | Quad ARMCortex-A9 1.0GHz 1MBL2cache | ||||
| RAM | 2 GB | ||||
| FLASH |
2GB
SSD(eMMC),
1.5GB free for application |
||||
Size diagonal |
7" diagonal | ||||
| Resolution | 800x480 pixels | ||||
| Number of serial ports | 1 Port 9pin DSUB | ||||
| Serial port 1 | RS 232 (RTS/CTS) | ||||
| Serial port 2 | RS422/485 | ||||
| Serial port 3 | - | ||||
| Serial port 6 | - | ||||
| Number of Ethernet ports | 2 | ||||
| Ethernet port 1 | 1x10/100 Base-T (shielded RJ45) | ||||
| Ethernet port 2 |
1x10/100 Base-T (shielded RJ45) |
||||
| Operating temperature | -10°C to +60°C | ||||
| Sealing front | IP65 | ||||
