| Mechanical size |
202 x 152 x 37 mm
Panel Mount
|
||||
| Cut-out size | 186 x 136 mm | ||||
| Housing material | Plastic (PC+ABS), Gray | ||||
| Input voltage | 18-32 VDC | ||||
| CPU | ARM Cortex A8 600MHz | ||||
| RAM | 512 MB | ||||
| FLASH | 2 GB | ||||
Size diagonal |
7.0" diagonal | ||||
| Resolution | 800 × 480 pixel (5:3) | ||||
| Number of serial ports | 1port9pinDsub, 1port3pinScrew | ||||
| Serial port 1 | RS 232 (RTS/CTS) | ||||
| Serial port 2 | RS422/485 | ||||
| Serial port 3 | RS485 | ||||
| Serial port 6 | RS485 | ||||
| Number of Ethernet ports | 1 | ||||
| Ethernet port 1 |
1x10/100 Base-T
(shielded RJ45)
|
||||
| Ethernet port 2 | - | ||||
| Operating temperature | -10°C to +50°C | ||||
| Sealing front | IP65 | ||||
