| Mechanical size |
170 x 107 x 49 mm
Panel Mount |
||||
| Cut-out size | 161 x 93 mm | ||||
| Housing material | Plastic (PC+ABS), Gray | ||||
| Input voltage | 18-32 VDC | ||||
| CPU | ARM9 400 MHz | ||||
| RAM | 128 MB | ||||
| FLASH | 200 MB | ||||
Size diagonal |
5" diagonal | ||||
| Resolution | 800x480 pixels | ||||
| Number of serial ports | 2 Port 9pin DSUB | ||||
| Serial port 1 | RS 232 (RTS/CTS) | ||||
| Serial port 2 | RS422/485 | ||||
| Serial port 3 | RS 232 | ||||
| Serial port 4 | RS 485 | ||||
| Number of Ethernet ports | 1 | ||||
| Ethernet port 1 |
1x10/100
Base-
T (shielded RJ45) |
||||
| Ethernet port 2 | - | ||||
| Operating temperature | -10°C to +50°C | ||||
| Sealing front | IP65 | ||||
