Mechanical size | 145 x 104 x 50 mm Panel Mount, VESA 50 x 50 | ||||
Cut-out size | 130 x 89 mm | ||||
Housing material | Powder-coated aluminum, Gray | ||||
Input voltage | 18-32 VDC | ||||
CPU | i.MX6Solo Single Cortex-A9 1.0GHz 512kBL2cache | ||||
RAM | 512 MB | ||||
FLASH | 2GB SSD(eMMC), 1.5GB free for application | ||||
Size diagonal |
4.3″ diagonal | ||||
Resolution | 480x272 pixels | ||||
Number of serial ports | 1 Port 9pin DSUB | ||||
Serial port 1 | RS 232 (RTS/CTS) | ||||
Serial port 2 | RS422/485 | ||||
Serial port 3 | RS485 (only if COM 2 is RS485) | ||||
Number of Ethernet ports | 1 | ||||
Ethernet port 1 | 1x10/100 Base-T (shielded RJ45) | ||||
Ethernet port 2 | - | ||||
Operating temperature | -10°C to +60°C | ||||
Sealing front | IP66 | ||||
