Stok Kodu
2682240000
Stok Durumu
Stokta Yok
| Total ports number | 8 | ||||
| 10/100TX ports | 8 x RJ45 | ||||
| LED indicator | Power LED | ||||
| RJ45 ports | 10/100BaseT(X), auto negotiation, Full-/half-duplex mode, Auto MDI/MDI-X port | ||||
| Connection type | 1 removable 4-pin terminal block | ||||
| Voltage supply range | 12-48 V DC | ||||
| Housing/protection (IP) | IP30/Metal | ||||
| Dimension | H 115 x W 41 x D 84 mm | ||||
| Mounting type | DIN rail | ||||
| Operating temperature | -40~75°C | ||||
| Overload current protection Reverse polarity protection | Yes | ||||
| Bandwidth backplane | 20 Gbps | ||||
| Jumbo frame support | up to 9 KB | ||||
| MAC table size | 4 K | ||||
| Packet buffer size | 1.5 Mbit | ||||
