| Nominal voltage (III/3) | 800 V | ||||
| Rated current | 2.5 mm2 - 24 A, 4 mm2 - 32 A | ||||
| Ex Ratings per |
ATEX: PTB 03 ATEX 1162 U / IECEx: PTB 03.0004U
(Ex eb IIC Gb) |
||||
| Rated voltage EN (Ex e II) | 550 V | ||||
| Rated current (Ex e II) | 22 A (20 A with jumper) | ||||
| Total number of connection points | 2 | ||||
| Number of jumper slots | 2 | ||||
| Connection technology | Push-in CAGE CLAMP® | ||||
| Actuation type | Push-in Operating tool |
||||
| Connectable conductor materials | Copper | ||||
| Solid conductor | 0.25 … 4 mm² / 22 … 12 AWG | ||||
| Color | Orange | ||||
