| Nominal voltage (III/3) | 800 V | ||||
| Rated current | 1.5 mm2 - 18 A, 2.5 mm2 - 24 A | ||||
| Ex Ratings per |
ATEX: PTB 05 ATEX 1094 U / IECEx: PTB 05.0034U
(Ex eb IIC Gb) |
||||
| Rated voltage EN (Ex e II) | 550 V | ||||
| Rated current (Ex e II) | 17 A ( 16 A with jumper) | ||||
| Total number of connection points | 2 | ||||
| Number of jumper slots | 2 | ||||
| Connection technology | Push-in CAGE CLAMP® | ||||
| Actuation type | Push-in Operating tool |
||||
| Connectable conductor materials | Copper | ||||
| Solid conductor | 0.25 … 2.5 mm² / 22 … 14 AWG | ||||
| Color | Gray | ||||
